Electric Tunnel Thruster CT 300
The CT300 is suitable for motor yachts and deep footed sailing boats from 48’ up to 93’. Designed for use with the popular 300mm tunnel diameter, this 48V electric tunnel thruster is a direct replacement for older less powerful 24V units.
With the 48V variant we have 48% decrease in amperage consumption and 50% increase in operation cycle, in relation to the 24V equivalent model, which makes it a cost efficient solution (smaller cables, supply from the same home batteries which results in lower installation costs).
* Thrusters are designed to run at 45.6V on 48V units. Higher voltages will result in higher thrust ratings, higher power consumption, and a reduced duty cycle.
* Performance data is given for a thruster installed at an immersion depth of one tunnel’s diameter, in a tunnel no longer than twice the tunnel’s diameter, and this within a variation of + / - 6%. Longer tunnels will result in lower thrust ratings and higher power consumption.
* Performance data is given for a thruster installed at an immersion depth of one tunnel’s diameter, in a tunnel no longer than twice the tunnel’s diameter, and this within a variation of + / - 6%. Longer tunnels will result in lower thrust ratings and higher power consumption.
| Code | Description | Voltage | Thrust | Propellers | Power | Weight | A | B | C | D | E | Drive Leg (material) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
![[] MAXPOWER THRUSTER CT300 ELEC DUO METALLIC 24V Ø300 image](https://www.max-power.com/images/items/itm_42542_317606.jpg)
|
MAXPOWER THRUSTER CT300 ELEC DUO METALLIC 24V Ø300 | 24V | 300(kg) / 660 (lbs) | 2 | 19.7(kw) / 26.4(hp) | 58.5(kg) | 250(mm) | 250(mm) | 480(mm) | 300(mm) | 9 - 10(mm) | Bronze |
| 636656 | MAXPOWER THRUSTER CT300 ELEC DUO METALLIC 48V Ø300 | 48V | 275(kg) / 606 (lbs) | 2 | 17.5(kw) / 23.8 (hp) | 64 (kg) | 250(mm) | 250(mm) | 480(mm) | 300(mm) | 9 - 10(mm) | Bronze |
