Hydraulic Retractable Thruster R300
R 300 benefits from evolutions already pioneered on the R 450. Both light & powerful this unit has been consistently trusted by designers around the world for many years and is ideal for yachts from 60’-104’.
|
Features |
|
| Power ratings (hp) | 20/34 |
| Thrust: | 11 kg per kw |
| Max. hydraulic power (kw): | 25 |
| Hydraulic power requirements (up to): | 35 lpm/ 260 bar - 55 lpm/ 270 bar |
| Power pack options: | PTO &24V |
| Hydraulic motor: | Piston |
| Opening/ closing mechanism: | Electric & manual |
| Propellers: | Duo, 3 blades |
| Weight (kg): | 73 |
*For further details on full package units, assemblies and components, please contact us.
| Code | Description | Model | HP | KW | Flow (LPM) | Pressure (BAR) | Motor |
|---|---|---|---|---|---|---|---|
| 317810 | MAX POWER THRUSTER R300/15 | R300/15 | 14.74 | 11 | 29 LPM | 240 B | 15cc |
![[] MAX POWER THRUSTER R300/21 image](https://www.max-power.com/images/items/itm_317807_317809.jpg)
|
MAX POWER THRUSTER R300/21 | R300/21 | 23.59 | 17.6 | 44 LPM | 240 B | 21cc |
