Hydraulic Retractable Thruster R200
Benefiting from a control system redesign, the R200 is the smallest model in the Max Power RetractTM range. Designed for top end production boats, this hydraulic retractable thruster has long been installed in prestigious yachts ranging from 45 - 68’.
| Features | |
| Power ratings (hp) | 10/17 |
| Thrust: | 10 kg per kw |
| Max. hydraulic power (kw): | 13 |
| Hydraulic power requirements (up to): | 20 lpm/ 220 bar - 30 lpm/ 250 bar |
| Power pack options: | PTO &24V |
| Hydraulic motor: | Piston |
| Opening/ closing mechanism: | Electric & manual |
| Propellers: | Duo, 2 blades |
| Weight (kg): | 35 |
*For further details on full package units, assemblies and components, please contact us.
| Code | Description | Model | HP | KW | Flow (LPM) | Pressure (BAR) | Motor |
|---|---|---|---|---|---|---|---|
![[] MAXPOWER THRUSTER R200/6 image](https://www.max-power.com/images/items/itm_317801__802.jpg)
|
MAXPOWER THRUSTER R200/6 | R200/6 | 10.72 | 8 | 22 LPM | 220 B | 6cc |
|
|
MAX POWER THRUSTER R200/8 | R200/8 | 16.08 | 12 | 30 LPM | 240 B | 8 cc |
Installation Manuals
Data Sheets
Technical Drawings
3D Models
