CT1000 is ready to enlarge the range of MAX POWER Tunnel Thrusters for boats up to 55m. All parts that are in the water are designed with best hydrodynamic profile to avoid turbulence. It is the most powerful tunnel thruster in D500 tunnel size with 4 blade propellers in metallic material to guarantee maximum thrust performance. Counter rotating system offers higher efficiency on thrusting with left side and right side pitch props in order to have same results in both directions

Code Thruster Power (kw) Motor Power (cc/kw) Tunnel diameter (mm) Pressure Flow Propellers Weight Light Duty Thrust (Kgf) Heavy Duty Thrust (Kgf) Application (Boat Size - m) A B C D
636428 Min 70 - Max 85 80,4 500 Min 210 - Max 250 200 Four Blade, DUO Counter Rotating 145 1200 1000 30-52 251mm 640mm 322mm 488mm
